Portalgraph NES 3D Emulator

A Nintendo Entertainment System (NES) emulator that lets you enjoy classic NES games in stereoscopic 3D using Portalgraph.

It converts NES games into a 3D scene and uses your PC's built-in camera to track your head, allowing you to look into the game world from different angles. It also supports red/cyan anaglyph 3D, so you can experience stereoscopic gameplay with inexpensive red/cyan glasses.

Supported Mappers

0, 1, 2, 3, 4, 7, 9, 10,
18, 19, 21, 22, 23, 24, 25, 26,
66, 67, 68, 69, 72, 73, 75, 76,
85, 86, 87, 88, 89, 93, 95,
140, 154, 184, 206, 210
Please use only NES ROMs that you legally own.

3D Profiles

Each game requires a 3D profile (.nesprof) to display correctly in 3D.

A profile has the same filename as the ROM, with the .nesprof extension.

Example:

SuperMario.nes
SuperMario.nesprof

Press F3 while playing to open the 3D Profile Editor.

From there, you can adjust the depth and shape of individual background and sprite tiles to create a convincing 3D effect.

Ready-made profiles are currently available for:

• Super Mario Bros.
• Xevious
• Gradius
• Star Force
• Ice Climber

After downloading a profile, place it in the same folder as the corresponding ROM.

Requirements

The Portalgraph Runtime is required.

https://portalgraph.itch.io/portalgraph-runtime

For basic operation, you'll need:

• A Windows PC with a webcam (for head tracking)
• Red/cyan anaglyph 3D glasses (for stereoscopic viewing)

For an even more immersive experience, Portalgraph also supports:

• VIVE Trackers
• 3D projectors

Keyboard Shortcuts

Key	Function
F1	Load ROM
F2	Toggle background color
F3	3D Profile Editor
F5	Reset
F6	Quick Save
F7	Quick Load
F12	Portalgraph Settings

Controls

Xbox controllers are supported.

Keyboard	NES Button
Arrow Keys	D-Pad
J	A
K	B
U	Auto-fire A
L	Auto-fire B
Enter	START
Right Shift	SELECT
